Product Details
Features
● New C type LED Lightbar with double layers Linear LED Modules. Brighter and Long Service Life.
● The shell is made of high-strength polycarbonate with good compression resistance and light transmission.
● The base is made of aluminum alloy, which is resistant to corrosion, oxidation and good heat conduction.
● With 1W High-Power LED as lamp source, and total 8pcs Linear LED Modules and 6pcs 4D LED Modules.
● LEDs available in single and dual color combinations of Red, Blue, Amber and White.
● Shells available in single and dual color combinations of Red, Blue, Amber and Clear.
● Can be used with Siren and Speaker, Speaker is installed inside the middle cover.
● 3 kinds of flash patterns automatically flashing.
● Mounting: Fixed with brackets, hooks and bolts.
● The general length of lightbar is 48".
● Welcome to customize the lightbars of different sizes, colors and flashing types.
● Warranty: 5 Years
Specification
Model No.
TBD-1622M
Voltage
DC12V
Current
≤8 A
Output Power
96W
Lamp Source
1W High-Power LED
LED Color
Red / Blue / Amber / White
Lens Color
Red / Blue / Amber
Operating Temp
-40℃ ～ +65℃
Material
Aluminum Base and PC Lens
Dimensions (LxWxH)
1240x373x140 mm
Carton Size
1150x350x180 mm, 1 Set/Ctn
Weight
15 kg
Mounting
Fixed with Brackets and Hooks
Configuration
9M Linease LED Modules: 8 PCS
4D LED Modules: 6 PCS
100Watts Speaker: 1 PC
